The multifunctional LCD programming box for selected XDFly series controllers is used for easy and quick programming of controllers - at home "on the table" as well as at the airport. In addition, it can serve as a servo tester, it can also measure the width and frequency of signal pulses, e.g. at the output of the receiver. It is also equipped with an input allowing you to measure the total voltage and the voltage of individual cells of 2-8S lithium battery packs.
1. PROGRAMMING THE CONTROLLER
The controller is connected using a servo cable or a special programming cable (depending on the type of controller), the sockets are located on the left side of the box. The box is powered from the BEC stabilizer of the XDFly controller. Programming is carried out with the motor and drive battery connected.
Four buttons on the front panel of the box are used for programming. With their help, you select the program functions ("ITEM") for adjustment and use the arrow buttons to set their value. The "OK" button confirms the change and sends it to the controller. The name of the program function and its value are displayed on the two-line LCD display.
The method of connecting the controller to the Multifunctional LCD Programming Box depends on the type of controller - it varies depending on whether the controller has a special programming cable or socket, etc. When connecting, follow the instructions supplied with the box and your controller exactly.
2. MEASURING THE WIDTH AND FREQUENCY OF SERVO SIGNAL PULSES
When connected to the receiver's channel output, the LCD programming box allows you to measure the frequency and width of the control pulses of the width-modulated control signal (PWM) for classic servos.
3. SERVOTESTER
The LCD programming box can also function as a control signal source for testing servos, controllers and other modeling devices. In this case, it is necessary to connect a power source (e.g. a receiver battery) to power the LCD programmer and the servo under test.
4. VOLTMETER FOR CHECKING THE VOLTAGE OF LITHIUM BATTERIES
Connect the service connector of the set to the "BATTERY CHECK" socket on the right side of the box; the voltage of the entire set and individual cells will then appear on the display. (When measuring voltage, the LCD programming box is powered from the service connector of the measured set, it does not need an additional power source.)
Compatible XDFly controllers
The programmer set includes: multifunctional LCD programming box, 3- and 4-wire connecting cable, instructions.
| Power supply [V] | 5 - 12.6 |
| Length [mm] | 84 |
| Width [mm] | 49 |
| Height [mm] | 11.5 |
| Weight [g] | 40 |
