E-flite EC-1500 Twin 1.5m PNP

Advantage of the Plug-N-Play® version

Airplanes in the Plug-N-Play (PNP) version facilitate preparation for flight quickly and with a minimum of time. You take the model out of the box, it has the motors, controller and servos installed, so all you have to do is final assembly, insert your own drive battery, install your RC kit and you're off to the airport!

SMART technology

Both the PNP and BNF Basic versions are equipped with a special Spektrum™ Avian™ Dual Smart Lite controller, which can provide a range of real-time power system-related telemetry data, including battery voltage, controller temperature and more – with the Smart and regular battery, via compatible receivers and of Spektrum AirWare™ equipped transmitters (including DX6e and 8e, DX6 G2/3 and 8 G2, DX9, NX6, 8, 10 and 20, iX12, iX14, iX20 and others), in real time. In addition, reversing and differential thrust offer improved ground handling for easier taxiing, take-off and landing, along with the ability to perform special aerobatic maneuvers.

Unique abilities

The E-flite EC-1500 Twin RC airplane model can be flown by both moderately experienced and demanding pilots. The model can be a good lamb as well with a suitable setting and with a 4S LiPol battery a real predator. You will experience the most fun flying with a twin-engine model. It has LED lighting installed and a folding cargo door. You can optionally bring your own camera, mount skis on the snow or order and mount floats. Fly on runway, snow and water. You have never had a more versatile model.

Wing configuration options

Functional flaps are divided and you can therefore have a larger area of flaps or ailerons. Or you can mix ailerons for flaps and have ailerons along the entire span of the wing. The agility of the model is incomparably greater and the model is an acrobat with two engines! Add to that the possibility of differentiating the thrust of the engines and you have a plane of new unimagined possibilities.

Compatible with 3S and 4S LiPol

Two high-performance AC motors with 5-blade counter-rotating propellers and two AC controllers with Y cable and EC5 connector are installed in the model, which are compatible with 3S 3200-6400 mAh LiPol battery, which is quite enough for normal sports flying. If you want to use the full capabilities of the model, use a 4S LiPol battery with an EC3 or IC3 connector for hanging and advanced acrobatics.

Functional cargo door

The installed servo controls the cargo door, which has dimensions of 65 x 107mm and cargo space of 65 x 107 x 323mm. It can be used to transport and drop payloads such as paratroopers, parachutes, candy and the like.

Model control

A total of 8 servos are installed in the model, they have metal gears on the rudders, the rudders have reliable hinges and the steered front wheel has its own servo. A separate BEC ensures reliable power supply to the on-board system.

Lighting with LED diodes

Realistic LED lighting includes landing lights in the wing, color-coded outline lights and flashing lights. They are completely installed already in production and powered by a flight battery.

Versatile options thanks to accessories

The EC-1500 Twin model can be launched from various surfaces or from snow using the included skis. You can also install an optional float kit (sold separately) using the included mounting accessories and fly on the water surface. Enjoy flying in any season on land, snow or water.

Easy and quick assembly

No glue is needed for final assembly and you can have the EC-1500 Twin ready to fly before you charge the battery! Two-piece wing with innovative hands-free connector connection, can be easily disassembled for convenient storage and transport. Hand-tightened thumbscrews are used, so no tools are required for assembly / disassembly in the field.

Big, light and durable

Don't be fooled by the 1.5m wingspan, with a large area wing, massive fuselage and large tail surfaces with a high rudder, the EC-1500 is bigger than you might think. However, it is still light and extremely durable, thanks to the composite light and stiff EPO material from which the model is made.

Marking selection option

The attached decal sheet allows you to adapt the coloring of the model to your imagination. Civilian Air Force, Army, Coast Guard, Marine Corps, and Navy decals are available.

Option to install a camera

The magnetically secured nose of the fuselage can be easily removed and a sports camera (GoPro® etc.) can be installed to record the flight of the model (cameras are not included). You can also install a separate FPV camera in the mounting space at the top of the magnetically secured top cover above the cabin (FPV camera / VTX are not included).

Level 3 - Experience required

Aircraft models with Experience Level 3 are suitable for more experienced RC pilots who already know how to set up and fly models of a similar class. This PNP version requires more experience and skill to build and fly than the BNF Basic version, as you will need to install a receiver that no longer includes properly tuned AS3X and SAFE Select technologies. It is therefore not suitable as a first RC plane for new pilots, you should have experience and skills with training models, even twin-engine ones like E-flite Twin Timber 1.6m or Timber X 1.2m, Extra 300 3D 1, 3 m, Ultra Stick 1.1 m and other similar models.

Recommended Spektrum transmitters

To pair the BNF version model, we recommend modern SPEKTRUM programmable transmitters:

•

• 6-channel DX Spektrum DX6e DSMX series transmitter with telemetry, 250 models in memory .

• 6-channel transmitter of the NX Spektrum NX6 DSMX series with the latest trends, Smart Technology compatibility, USB port and WiFi connectivity .

• 8-channel transmitter of the NX Spektrum NX8 DSMX series with the latest trends, Smart Technology compatibility, USB port and WiFi connectivity .


Recommended batteries

To power the model, we recommend a driving LiPol battery with 3 or 4 cells (11.1 V, 14.8 V).

•

• For general flying LiPo battery Spektrum Smart LiPo 11.1V 4000mAh 30C IC3 with technology Smart .

• For longer flights Spektrum Smart G2 LiPo 11.1V 5000mAh 30C IC5 LiPo battery with Smart technology

• For greater performance LiPo battery Spektrum Smart LiPo 14.8V 4000mAh 30C IC3 with Smart technology

• For maximum performance and flight time LiPo battery Spektrum Smart LiPo 14.8V 5000mAh 30C IC5 with Smart technology


Spektrum batteries with Smart technology currently represent the most modern and safest way to maintain and charge batteries. The benefits of Spektrum Smart technology can be found here.

Recommended chargers for conventional LiPol and Smart batteries

If you decide to use modern Smart LiPo batteries in RC models of airplanes or helicopters, or to charge your batteries from other manufacturers, then we recommend the following chargers:

•

• Network charger Spektrum S155 with one output 1x 55W .

• Network charger Spektrum S1100 with one output 1x 100W .

• Network charger Spektrum S2100 with one output 2x 100W .

• Network charger Spektrum S2200 with two outputs 2x 200W .


Accessories for normal operation

For the normal operation of flying RC models, you need suitable adhesives, a set of tools and a storage case for LiPol batteries. From our assortment, we recommend a quality set of 1.5/2.0/2.5/3.0mm allen screwdrivers and Modelcraft Phillips screwdrivers (set of 6). Modelcraft mini pliers in a case (set) will certainly come in handy for assembly, and for cutting a Modelcraft cutting knife with an A6 pad.

For quick repair of model airplanes, we recommend the fast-curing 4-minute Epoxy glue. From our offer, we recommend Speed Epoxy 4 min. 71g

Protective covers for accumulators

Protective packaging is intended to limit the risk associated with the transport and charging of accumulators. LiPo accumulators, while maintaining small dimensions and low weight, can provide high discharge currents and have a large capacity. The LiPo battery is particularly susceptible to mechanical damage and therefore needs to be thoroughly protected.
