ManiaX Lipo 7.4V 1300mAh 30C

MAX2018
ManiaX
ManiaX LiPo battery pack with 30/60C load capacity, 1-3C charging, max. 5C. Two-cell 2S 11.1V 1300 mAh, dimensions: 75x34x15mm, weight: 76g, XT60 + JST-XH service connector.
More info

Sale is over



Express delivery



Large selection of carriers



Satisfaction guarantee



Lithium polymer batteries of the ManiaX ECO 30/60C series reliably cover the needs of the recreational modeler: they have a maximum discharge current of 30C, the possibility of fast charging of 1-3C, a wide range of capacities (450-5000 mAh), excellent long-term durability and a favorable price.

Lithium polymer batteries of the ManiaX ECO 30/60C series with a current load capacity of max. 30C are intended for common applications in recreational and sports aircraft models for classic and 3D aerobatics. High current capacity guarantees maximum use of engine power and allows for a relatively vigorous flying style while maintaining a very good long-term service life.

Do not charge ManiaX ECO 30/60C series batteries with a current greater than 5C; for normal operation, we recommend using currents in the range of 1-3C. We recommend using a balancer with each charge. ManiaX ECO 30/60C series batteries do not require initial conditioning, but if you intend to charge the sets with a current greater than 1C, we recommend not exceeding 1C for the first three charging cycles. There is no need to discharge them before charging - for example, you can safely charge batteries that are 50% discharged.

The set is supplied in a design designed primarily for powering model airplanes and helicopters. It is equipped with silicone power (charging) cables with a cross-section dimensioned with respect to the expected current load. The service connector is of the standard JST-XH system type - it has small dimensions and low weight (which will be especially appreciated by users of small capacity kits), has simple connection of the pins and can even be connected directly to the balancer sockets on many KAVAN, SkyRC, GT Power, etc. chargers without using any adapter.

The kit includes: ManiaX ECO 30/60C battery, instructions.

Capacity [mAh]1300
Voltage [V]7.4
Charging current [A]1.3 - 3.9
Max. charging current [A] 6.5
Discharge current [A]39
Max. discharge current [A]78
Energy [Wh]9.6
Length [mm]75
Width [mm]34
Height [mm]15
Weight [g]76
Délka [mm]
75
Hmotnost [g]
76
Nabíjecí proud [A]
1.3 - 3.9
Vybíjecí proud [A]
39
Šířka [mm]
34
Výška [mm]
15
Kapacita [mAh]
1300
Napětí [V]
7.4
Max. nabíjecí proud [A]
6.5
Max. vybíjecí proud [A]
78
Energie [Wh]
9.6
