Ultra fast narrowband (760µs) digital standard servo with AC motor, metal gears and output shaft mounted on two ball bearings. Ideal for 600 size helicopter trim rotors, compatible with most 760µs gyros and flybarless units. For perfect cooling even under heavy load, the servo is housed in a box with an aluminum middle part. The servo is not programmable.
Supply voltage 6.0-7.4 V (nominal).
| Servo size | Standard |
| Servo type | Digital |
| Programmable | No |
| Thrust at 6.0 V [kg•cm] | 4.2 |
| Thrust at 7.4 V [kg•cm] | 5.1 |
| Thrust at 8.2 V [kg•cm] | 5.7 |
| Speed at 6.0 V [s/60°] | 0.05 |
| Speed at 7.4 V [s/60°] | 0.05 |
| Speed at 8.2 V [s/60°] | 0.03 |
| Control pulse width in neutral [µs] | 760 |
| Repetition frequency [Hz] | 560 |
| Deadband [ms] | 0.0005 |
| Servo transmissions | Metal |
| Ball bearings | 2× |
| High voltage | Yes |
| Power supply [V] | 6 - 8.4 |
| Length [mm] | 40 |
| Width [mm] | 20 |
| Height [mm] | 40 |
| Weight [g] | 63 |
| Intended for | Helicopters |
