Sports semi-model of aerobatic aircraft for propulsion by AC electric motor 1200-1600 W and 6S LiPo for experienced pilots for flying classic precise and extreme 3D acrobatics.
The fuselage of the model is a classic construction of plywood and balsa laser cut parts reinforced with Kevlar® and carbon with a removable laminate engine cover and a removable upper fuselage with a cabin for perfect access to the propulsion system and RC equipment. The engine is fixed in the rear assembly on a plywood box bed.
The two-piece wing with symmetrical profile (the halves slide from the side onto the carbon tube coupler and secure with screws) is also a classic construction with an all-balsa rigid skin. The wings with a large area are controlled by 2 independent servos. You can equip the ends of the wings with the supplied SFG winglets.
The tail surfaces are all-balsa construction, the VOP is one-piece with a stabilizer glued to the fuselage. The elevator and rudder are controlled by a servo located in the tail part of the fuselage with a short straight rod. The entire model is coated with ULTRACOTE iron-on foil (this is the brand name used in the USA for the well-known Oracover foils).
The chassis is a spur type with carbon main legs, lightweight wheels with laminate covers and a wire spur with a carbon bracket mated to the turn signal.
For the drive, you will need an AC electric motor 1200-1600 W (e.g. KAVAN PRO 5050-515) with an 80-100 A speed controller powered by a 6S LiPo battery 3300-4000 mAh with a load capacity of at least 40C.
At least a four-channel computer RC set is suitable for controlling the model - the possibility of programming double and exponential deflections in the right size is essential for flying acrobatics - classic precision and extreme 3D.
Servos that are fast and powerful in a mini size will do – e.g. KAVAN GO-1035MG, etc.
Kit includes: iron-on foil covered fuselage, wing and tail surfaces, sprayed laminate engine cover, complete accessory kit, carbon undercarriage, spur, light wheels and instructions.
| Span [mm] | 1524 |
| Length [mm] | 1500 |
| Wing area [dm 2 ] | 42.3 |
| Weight [g] | 2750 - 2850 |
| Controlled functions | S,V,K(2),M |
| Difficulty of construction | S1 |
| Difficulty of piloting | P3, P4 |
Recommended drive and RC equipment:
| Engine | CAVAN FOR 5050-515 |
| Regulator | CAVAN FOR R-100SB |
| Accumulator | KAVAN 22.2 V 3300 mAh 40/80C |
| Propeller | CAVAN 16x8" |
| Serve | 4x HS-5245MG |
| Servo HV | 4x KAVAN GO-1035MG |
| RC kit | min. 4 channels |
