KAVAN Smart PRO-45LV SBEC

Powerful BLDC motor controller with continuous current up to 40 A at voltage up to 26 V (6S LiPo). It is suitable for smaller models - typically electric wind turbines. It offers a high-quality stabilized voltage output (BEC) with continuous current up to 10 A. With a load capacity of up to 60 A for 30 s, it is ideal for F5J type models.

The Smart PRO product line represents advanced speed controllers for use primarily in radio-controlled model aircraft. With integrated telemetry and various user-configurable options, the controllers offer high efficiency, low weight and precise motor control. The controllers offer many types of protection.

Features

• Small dimensions combined with high-performance motor control.
• Powerful switching BEC that offers 10A continuous current (20A max). BEC circuit protection against overcurrent and overheating is included.
• BEC voltage adjustment in 0.1 V steps.
• Overvoltage and undervoltage protection, overheating protection, motor stall protection.
• Adjustable current limiter.
• Safety shutdown in case of loss of pulse.
• Configurable acceleration, timing, electromagnetic brake, etc.
• Configuration directly in the KAVAN transmitter with the ETHOS operating system using Lua scripts
• Low acoustic noise thanks to high-frequency switching.
• Automatic telemetry detection: FrSky/KAVAN FPort, JETI Duplex EX, Graupner Hott, Multiplex MSB, Futaba S.Bus2, PowerBox P2Bus. Special firmware with Spektrum SRXL2 support.
• Telemetry (depending on RC system): voltage, current, power, capacity, temperature, speed, energy.
• Minimum/maximum telemetry values are recorded.
• Configuration via transmitter or external terminal (JETIBOX/SMART-BOX).
• Firmware update via USB interface and MAV Manager program.
• Languages: CZ/DE/EN/FR/IT

Other features:

• Possibility of activating synchronous switching (Active Freewheeling) for more precise motor response and less heating of the controller during aerobatics.
• Trouble-free operation with powerful multi-pole motors and the vast majority of all other motors.
• Optional connection of a backup battery without additional reductions.
• Without the option of an external switch, propeller positioning and the possibility of connecting an external temperature sensor.

Package includes: Speed controller, instructions.

KAVAN Smart PRO-45LV SBEC is manufactured in the Czech Republic by MAV Sense sro

Online manual: wiki.kavanrc.com
