The Baja 5B is back as a kit!
Big scale fans, we hear you! The ORIGINAL HPI Baja 5B is BACK and ready to build from A to Z! The HPI SBK (Self Build Kit) collection is expanding with not just one, but two 1/5 scale model kits! Fans of large-scale off-road RC cars will be thrilled to be able to build their own Baja 5B, powered by internal combustion GAS or AC electric FLUX drive!
The Ultimate HPI Self Build Kit!!
Build a legend! Experience the thrill of building a car that reaches a length of over 80cm and a weight of almost 10 kilograms! During construction, you just add your own electronic components (in the case of the internal combustion version, an additional engine) and you will be ready for any adventure!
When the HPI Baja 5B Buggy was first introduced, large scale models were very expensive and challenging for the average RC modeler. But now, using highly durable materials and innovative design solutions, HPI is bringing this massive off-roader to new enthusiasts, ushering in a new era of BIGGER RC cars!
Both the HPI Baja 5B and Baja 5B FLUX are equipped with extra large and durable chassis components! With its expertly designed composite suspension, extra-long adjustable HD shocks and giant impact-resistant nylon wheels, the Baja 5B is ready to race on any off-road course!
Racing components in the package:
- Front and rear transverse stabilizers
- Super durable half axles #104966
- One Piece Rear Wheel Hinges #104781
- 24mm Heavy Duty Front Wheel Carriers #105612
PROPERTIES
- 1/5 scale off-road buggy
- Ready for your 23-32cc internal combustion RC engine, or 6S/8S combo
- Ready for your RC kit
- Closed receiver box
- Baja bodywork, specific to the GAS or FLUX version
- Adjustable HD dampers
- Self-supporting monocoque
- Low center of gravity for excellent handling
- High lift suspension
- Oil-filled planetary differential
- All-terrain tires and beadlock rims
- Aluminum rear suspension antlers
- Hard plastic protective plates
- Adjustable rear wing
- Quick access for maintenance of the most important components
- Two-axis steering
- Articulated servo saver
- Connecting material for hexagon
- Metal anodizing
- Complete with ball bearings with rubber seals
Chassis specification
- Total length: 817mm
- Height: 255mm
- Width: Front - 460mm, Rear - 480mm
- Track (between tire centers): Front - 395mm, Rear - 400mm
- Wheelbase: 570mm
- Ground clearance: 76mm
- Suspension travel: Front - 95mm, Rear - 100mm
- Weight: 9.6 kg
- Adjustable deflections: Front - washers, Rear - screws
- Front axle camber: Adjustable with washers 22/25.5*/29 degrees (* base)
- Toe-in: Front adjustable with connectors, Rear adjustable with inserts 0-4 degrees (base 3 degrees)
- 6061 T6 aircraft aluminum monocoque
- Double wishbone suspension with adjustable tilt center front and rear
- Gearbox with HD metal gears and closed case (gear ratio 8.382:1)
- Differential with stiffness adjustment using oil viscosity and four pinions
- Oil shock absorbers of HD construction with a thread to adjust the preload of the springs
- 3-part discs made of highly resistant nylon with metal carriers
Wheelbase [mm] | 570 |
Width [mm] | 480 |
Length [mm] | 817 |
Height [mm] | 255 |
Ground clearance [mm] | 76 |
Stroke [mm] | 95 |
Weight [kg] [kg] | 9.6 |
Engine type | Alternate |
Li-Po [Art.] | 8 |
Chassis type | Off-road, Durable, Buggy, Racing |
